1092 Toilet Paper Machine

Raw material:

recycled paper, virgin pulp

concentration:

0.2-0.4%

Paper dryness

Out of wire part:

13-18%

Go into dryer cylinder:

35-38%

Finished paper:

90-92%

Calculated running time:

24h

Design tension for felt:

4KN/m

Working tension:

3KN/m

Motor voltage

380VAC/50HZ

three-phase

220VAC/50HZ

single-phase

Control voltage:

220VAC/50HZ

Single-phase

24VDC

Air source pressure:

0.7-0.8MPa

Working pressure:

≤0.6MPa

Quality requirements:

Air for meter:

filtered, oilless, waterless

Air for machine:

common compressed air

Air supply temperature:

≤35℃

Requirements:

pure, colorless, desanding

Pressure:

2.0Mpa, 0.7MPa, 0.4MPa (High pressure water must be filtered by 40 filter mesh)

PH value

6-8

Solid content :

< 60g/1000L

Working pressure:

≤0.5MPa

Testing pressure:

1.0 MPa

Output：

Tissue paper, toilet paper, napkin, facial tissue

Paper weight：

13-35g/m²

Wire width:

1950mm

Paper width on pope reel:

1575mm

Working speed：

150-220m/min

Design speed：

250m/min

Capacity：

5-7 t/d

Type of transmission:

AC motor, FC and sectional driving

Rail space：

2400mm

Type of pressurization:

pneumatic pressurization

Main drive power:

50.5kw (dryer cylinder: 45kw, pope reel: 5.5kw)

Overall dimension：

13.9×5.9×5.8m(L×W×H)

Arrangement form:

Single-ply

The heaviest piece：

Dryer cylinder(about 15T)
