4400 Fluting Paper Making Machine

4400 Fluting Paper Making Machine is 4400mm Width and 200tpd Fully Automatic Fourdrinier Corrugated Paper and Pulp Making Machinery With Material Of Virgin Pulp, Waste Recycle Carton Box, and so on.

• Shipping Port :HANGZHOU
• Lead Time :4 Months
• Weight :100-1500 Tons
• Min. order :1 Set

• 4400mm Width and 200tpd Fully Automatic Fourdrinier Corrugated Paper and Pulp Making Machinery With Material Of Virgin Pulp, Waste Recycle Carton Box, and so on.
• Fluting Paper Machine model

This paper machine applies to make fluting paper with grammage 80-160gsm. The maximum width on pope reel is 4400mm, working speed is 350-400m/min, capacity 200 tons per day, calculate at 24 hours. It could design with left-hand or right-hand type based on drive position.

▼ Design tension for felt is 4KN/m, working tension is 3KN/m.

√ Stock Preparation -- Approach System -- Headbox -- Fourdrinier Wire -- Press Section -- Dryer Section -- Pope Reel -- Air Hood -- Rewinder -- Vacuum System -- Air Compressor -- Steam Condensate System

√ Concentration: 0.2-0.4%

√ Paper dryness out of wire part 13-18%, go into dryer cylinder 35-38%, at pope reel 90-92%.

Strict quality control department will conduct complete quality inspection, to make sure frame alignment, rubber roll coating and crown, and all parts are correct and perfect paking to deliver to our customer.

Before shipping we will assemble and test all parts in the pre-assembly workshop to ensure the alignment and integrity of the equipments, and complete all parts even nuts and bolts.

We will send engineer to customer paper mill to support on installation and machine test running, also will train the workers on opperation.

Turn-Key service is our advantage, we have professional design engineer, machnical engineer and production enginners all have rich experience on paper mill.

We will give you profesional design of production line with good price and low investment.

Corrugated and fluting paper making machine,cylinder mould type and fourdrinier wire design.Fluting paperis mainly used for corrugator board packing market,grammage from 60gsm to 160gsm.
